£23.99
The HLV5018V1 is perfect for replacing older style halogen sliding foot dimmers and running energy efficient LED bulbs.
Built in to the casing is an on / off switch. This means there is now no need to have a separate inline cord on / off switch!!
The circuit must be running 500mA.
These are a steal at the price we are retailing them for and are going to be very popular as LED technology advances.
Input Voltage: 220 – 240Vac
Input Frequency: 50Hz
Output Voltage: 10 – 18Vdc 19Vdc (Max)
Output Current: 500mA
Output Power: 5 – 9W
Ta: 45℃ Tc:80℃
1. Overload and short-circuit protection.
2. Temperature protection.
Approvals:
Safety: EN61347-1:2008, EN61347-2-13:2006
EMC: EN55015:2006+A1+A2, EN61000-3-3:2008, EN61000-3-2:2006, EN61547:1995+A1
Weight | 0.136 kg |
---|---|
Dimensions | 110 × 72 × 32 mm |
Condition | New |
Country Of Manufacture | China |
Dimmable | Yes |
Maximum Wattage | 9w |
Minimum Wattage | 5w |
MPN | HLV5018V1 |
Outputs | 1 |
Primary | 220 – 240v |
Secondary | 10 – 18Vdc, 19Vdc (Max) |
