Name: KAOYI KTB80 ELECTRONIC TRANSFORMER (DISCONTINUED)
SKU: KTB80
Availability: OutOfStock

Product Information

£0.00

This circular transformer can be installed in most light fittings where a circular transformer is required with a maximum output of 80va.

The Kaoyi KTB80 is one of Kaoyi’s more unusual transformers as it bridges the gap between 60va and 105va transformers and is not commonly found.

17/12/13 – The KTB80 has been discontinued but can be replaced with the Huibolong HTV80CL1.

SKU: KTB80

Category: Discontinued Models

Description
Additional information

A 20-80va electronic transformer for installation in light fittings requiring a maximum 80va output.
Dimmable with inductive and resistive dimmer.
Over-load protection and Short-circuit protection.
Soft Start extends bulb life.
Complies with: EN61347
EMC compliance: EN55015, EN61000, EN61547+A1.

Weight	0.12 kg
Dimensions	25 mm
Condition	New
Country Of Manufacture	China
Dimmable	Yes
Maximum Wattage	80w
Minimum Wattage	20w
MPN	KTB80
Outputs	1
Primary	220 – 240v
Secondary	12v
Diameter	76mm
