Name: WAIBERLON HLV3506L1 CONSTANT CURRENT LED DRIVER
SKU: HLV3506L1
Price: 15.99 GBP
Availability: InStock

Product Information

£15.99

This model is one of Huibolong’s newest compact LED Drivers with a rating of 6w and constant current of 350mA.
Small, compact and is ideal for light fittings or applications with limited space.

13/09/23 – This model can be used to replace the Eaglerise EBP006C0350SS LED Driver.

SKU: HLV3506L1

Categories: 12v Non-Dimmable, LED Drivers

Description
Additional information

Model: HLV3506L1
Output Current: 350mA
Load Voltage: 8 – 18Vdc
No Load Voltage: 21Vdc
Output Power: 6w
Over temperature, Short circuit and Overload protection
Safety Standards: EN61347-2-13, EN61347-1 ã€€ã€€ã€€
EMC: EN55015, EN61000-3-2, EN61000-3-3, EN61547

Weight	0.11 kg
Dimensions	43 × 43 × 20 mm
Condition	New
Country Of Manufacture	China
Maximum Wattage	6w
Minimum Wattage	3w
MPN	HLV3506L1
Outputs	1
Primary	220 – 240v 50/60Hz
Secondary	Constant Current – DC350mA 8 -18v
