£20.99
The HLV50031LA is one of Huibolong’s latest range of LED Drivers.
500mA is an unusual power band which is becoming more popular as LED lighting evolves.
This model gives a 31w LED output.
We can see these being popular as we advance into the LED era.
SaveMyLight is the only retailer of these LED drivers.
NOTE: The minimum load for this unit is 23w at 500mAH. If you do not have a minimum of 23w at 500mAH the unit will flash on and off repeatedly!! This is not a fault. Please do not purchase until your electrician has checked your circuit power.
This model can replace the Eaglerise EIP030C0500L1 / LX / LS
Model: HLV50031LA
Primary: 220 – 240v 50Hz 0.12A
Secondary: 46 – 62v 500mA
No Load Voltage: 72VDC
Output: 23 – 31w
Dimmable: No
EN61347-2-13, EN61347-1, EN55015, EN61000-3-2, EN61000-3-3, EN61547
Weight | 0.16 kg |
---|---|
Dimensions | 160 × 45 × 28 mm |
Condition | New |
Country Of Manufacture | China |
Maximum Wattage | 31w |
Minimum Wattage | 23w |
MPN | HLV50031LA |
Outputs | 1 |
Primary | 220 – 240v |
Secondary | 46 – 62v, 500mA |
